NEC MultiSync V801 TM 80" Display

Varenr.:
60003679 $DEL
EAN:
5028695110915
  • Skjermstørrelse 80"
  • Oppløsning 1920 x 1080
  • HD Full HD
  • USB-C 0
  • DVI 1
  • HDMI 1
  • Berøringsskjerm Ja
  • Høyttalere Ja
  • Skjermform Flat
  • Høydejustering Nei
  • Svivel Nei
  • Svingtapp Ja
  • Bruksområde Personal display
95 875,- Ekskl. mva
Ikke på lager
Gi beskjed når varen er på lager
Antall:
Legg i handlekurven
Beskrivelse
Spesifikasjoner

MultiSync® V801-TM (Multi-Touch)


NEC MultiSync® V801 TM is the new multi-touch product of NEC's V Series boasting 80" in size and delivering true multi-touch support with up to 6 simultaneous touch points. Thanks to anti reflective coating, reflections are reduced to a minimum which significantly increases the readability of the content shown. The OPS option slot for e.g. a slot-in PC helps to save space and does away with any cables.
V801 TM is ideal for any kind of interactive whiteboard applications in corporate meeting rooms and class rooms.

Features:
  • Multi-Touch - true multi-touch support with up to 6 simultaneous touch points for all major operating systems.
  • Infrared Touch - offering quick touch response and perfect usability.
  • Driver-free - no need to install any drivers on the host PC for all major operating systems. Interface to host PC is USB HID protocol with no drivers, calibration or application software on the host.
  • Calibration-free - due to robust and accurate design, no drift, mechanical alignment or temperature issues. No re-calibration of the touch system necessary.
  • Comprehensive Touch Usage - possible usage with Finger, Stylus and Gloves.
  • Protective Glass - double anti-reflection coating for perfect visibility, full-tempered glass for security.
  • Future Ready with OPS Cable Free Expansion - upgrade the power of your display at any time without the need for external cables or devices.
  • Free DisplayNote Multiuser Licence - present, share, collaborate with up to 5 participants across multiple devices (available until May 2015).
  • Special Characteristics - Advanced fan control; Copy display settings through RS232; DICOM support; Hardware colour calibration possible; Input name adjustment; Matrix memory; NaViSet Administrator 2; PIN as theft protection; Various picture in picture options; Rapid input switching; Scheduler; Screen saver functions; TileMatrix (10 x 10); User input priority definition; Ambient light sensor; Carbon savings meter; ECOMode

Specifications:

DISPLAY
Panel Technology UV² A with Edge LED backlight
Screen Size [inch/cm] 80 / 203.2
Aspect Ratio 16:9
Brightness [cd/m²] 320, (460 max)
Contrast Ratio (typ.) 5000:1
Viewing Angle [°] 176 horizontal / 176 vertical (typ. at contrast ratio 10:1)
Response Time (typ.) [ms] 6 (grey-to-grey)
Panel Refresh Rate [Hz] 60
Supported Orientation Landscape; Portrait
SYNCHRONISATION RATE
Horizontal Frequency [kHz] 31.5 - 91.1 (analog and digital)
Vertical Frequency [Hz] 50 - 85
RESOLUTION
Native Resolution 1920 x 1080 at 60 Hz
Supported on digital and analogue inputs (PC) 1600 x 1200; 1360 x 768; 1280 x 1024; 1280 x 768; 1024 x 768; 832 x 624; 800 x 600; 720 x 400; 640 x 480; 640 x 400
Supported on digital inputs (Video) 1920 x 1080i (59.94/60)16:9; 1920 x 1080i (59.94/60)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9
CONNECTIVITY
Input Video Analogue 1 x D-sub 15 pin; Composite (BNC); RGBHV for PC and Component/Composite (BNC)
Input Video Digital 1 x DisplayPort (with HDCP); 1 x DVI-D (with HDCP); 1 x HDMI 1.3 (with HDCP)
Input Audio Analogue 1 x 3,5 mm jack
Input Audio Digital 1 x HDMI; DisplayPort
Input Control LAN 100Mbit; remote control wire (3,5mm jack); RS232
Output Video Digital 1 x DVI-D (with HDCP)
Output Audio Analogue 3,5mm jack
Output Control RS232
Remote Control LAN with SNMP; Remote Control IR (internal/external (optional) sensor); RS-232C (9-pin D-sub) Input and Output
OPTION SLOT
Slot Technology STv2 (compatible with Intel / NEC OPS standard)
Inrush Current [A] max. 10
Power Consumption [W] max. 61
Voltage / Current [V/A] 16/4
ELECTRICAL
Power Consumption [W] 230 shipping; 420W max. (with built-in PC 100% workload)
Power Savings Mode [W] < 0.5 (ECO Standby); < 1
Power Management VESA DPMS
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C] +0 to +35
Operating Humidity [%] 20 to 80
Storage Humidity [%] 10 to 90
Storage Temperature [°C] -20 to +60
MECHANICAL
Dimensions (W x H x D) [mm] Without stand: 1,842.8 x 1,067.9 x 107.3
Weight [kg] Without stand: 79.9
Bezel Width [mm] 34.8 (left and right); 34.8 (top and bottom)
VESA Mounting [mm] 4 holes; 400 x 400 (FDMI); M8
GLASS
Thickness [mm] 5
Type Double sided anti-reflection, fully tempered
Light Transmission [%] 96 (+/- 2 %)
Reflection Rate [%] 2
TOUCH
Touch Technology Infrared Touch
Number of Touches Real multi-touch up to 6 touches
Response Time [ms] 0 to 20
Touch Method Finger; Gloves; Stylus
Operating System Native Multi-Touch (Windows7, Windows8); Single Touch (Windows X, Windows Vista, Linux, Mac OSX, Android)
Data Interface USB 2.0 (full speed) HID; USB powered, plug & play
Accuracy [mm] < 2
Touch Resolution 32767 x 32767
ADDITIONAL FEATURES
Special Characteristics Advanced fan control; Copy display settings through RS232; DICOM support; Hardware colour calibration possible; Input name adjustment; Matrix memory; NaViSet Administrator 2; PIN as theft protection; Rapid input switching; Scheduler; Screen saver functions; TileMatrix (10 x 10); User input priority definition; Various picture in picture options
Colour Versions Black Front Bezel, Black Back Cabinet
Safety and Ergonomics C-tick; CE; FCC Class B; PSB; RoHS; TÜV GS; UL/C-UL or CSA; VCCI
Audio Integrated Speakers (10 W + 10 W); Optional Speakers (15 W + 15 W)
Shipping Content CD-ROM (User Guides/Manuals); CD-ROM with Touch Drivers; Display; DVI-D cable; External Power Supply; Power Cable; Remote Control; USB cable
Warranty 3 years warranty incl. backlight
Operating Hours 16/7
AVAILABLE OPTIONS
Accessories Feet (ST-801); Speaker (SP-RM1, SP-TF1); Trolley (PDMHA); Wall mount (PDWHM-L, PDW T XL)
OPS HD-SDI 1.5G,3.5G; HDBaseT receiver; Slot-inPC (Intel® Core i5/i7 with WS7P recommended); Wireless Display Media Player
GREEN FEATURES
Energy Efficiency Ambient light sensor; Carbon savings meter; ECOMode
Ecological Materials Manuals on CD; Optional feet
