| Prosessorfrekvens | 2 GHz |
| Prosessorfamilie | Intel® Xeon® E5 Family |
| Prosessormodell | E5-2620 |
| Prosessorkjerner | 6 |
| Antall installerte prosessorer | 1 |
| Cachetype prosessor | Smart Cache |
| Processor cache | 15 MB |
| Systembussrate | 7,2 GT/s |
| Prosessorprodusent | Intel |
| Maksimalt antall SMP-prosessorer | 2 |
| Kompatible prosessorserier | Intel® Xeon® |
| Prosessorstøpsel | LGA 2011 (Socket R) |
| Systemkort kretsoppsett | Intel® C602J |
| Boostfrekvens prosessor | 2,5 GHz |
| Prosessorlitografi | 32 nm |
| Prosessortråder | 12 |
| Prosessorens driftmoduser | 64-bit |
| Stigning | C2 |
| FSB-paritet | Nei |
| Busstype | QPI |
| Antall QPI-koblinger | 2 |
| Kodenavn prosessor | Sandy Bridge EP |
| Tcase | 77,4 °C |
| Maksimalt internminne støttet av prosessor | 750 GB |
| Minnetyper som støttes av prosessor | DDR3-SDRAM |
| Minneklokkehastighet støttet av prosessor | 800,1066,1333 MHz |
| Minnebåndbredde støttet av prosessor (maks.) | 42,6 GB/s |
| Minnekanaler støttet av prosessor | Quad |
| EEC støttet av prosessor | Ja |
| Execute Disable Bit | Ja |
| Inaktive tilstander | Ja |
| Thermal Monitoring Technologies | Ja |
| Maksimalt antall PCI Express-spor | 40 |
| PCI Express-konfigurasjoner | x4, x8, x16 |
| Prosessorpakkestørrelse | 52.5 mm |
| Støttede instruksjonssett | AVX |
| Skalerbarhet | 2S |
| Physical Address Extension (PAE) | 46 bit |
| Integrerte alternativer tilgjengelige | Ja |
| Grafikk og IMC-litografi | 32 nm |
| Thermal Design Power (TDP) | 95 W |
| CPU-multiplikator (buss/kjerneforhold) | 25 |
| Prosessorserier | Intel Xeon E5-2600 |
| Konfliktfri prosessor | Nei |
| Internminne | 8 GB |
| Internminnetype | DDR3-SDRAM |
| Maksimalt internminne | 768 GB |
| Minnespor | 24 |
| ECC | Ja |
| Minneklokke-hastighet | 1600 MHz |
| Minnefordeling | 1 x 8 GB |
| HDD-størrelse | 2.5" |
| HDD-grensesnitt | Serial ATA III,Serial Attached SCSI (SAS) |
| RAID-støtte | Ja |
| RAID-nivåer | 0,1,10 |
| Maksimal lagringskapasitet | 25,6 TB |
| Antall støttede HDDer | 16 |
| S.M.A.R.T.-støtte | Ja |
| SSD drivergrensesnitt | Serial ATA III,Serial Attached SCSI |
| Hot-swap | Ja |
| Maks. skjermkortminne | 16 MB |
| On-board grafikkort | Ja |
| Ethernet/bredbåndsforbindelse | Ja |
| LAN-kontroller | Intel I350AM4 |
| Kablingsteknologi | 10/100/1000Base-T(X) |
| Ethernet-grensesnittype | Gigabit Ethernet |
| Antall USB 2.0-porter | 6 |
| Antall VGA (D-Sub)-porter | 2 |
| Antall ethernets-/bredbåndstilkoblinger (RJ-45) | 5 |
| Kommunikasjonsserieporter | 1 |
| PCI Express x8 (Gen 3.x) slots | 3 |
| PCI Express sporversjon | 3.0 |
| Chassis-type | Rack (2U) |
| Optisk stasjonstype | Nei |
| Redundante fans støtter | Ja |
| Trusted Platform Module (TPM) | Ja |
| Operativsystemprogramvare 04 | Nei |
| Kompatible operativsystemer | Microsoft Windows Server 2012 R2/2012, 2008 R2/2008, Red Hat Enterprise Linux 5/6, SUSE Linux Enterprise Server 10/11, VMware ESX 4.1, VMware ESXi 4.1, VMware vSphere 5/5.1 (ESXi) |
| Prosessorkonfigurasjon (maks.) | 2 |
| Intel® Rapid Storage Technology | Nei |
| Enhanced Intel SpeedStep Technology | Ja |
| Intel® Identity Protection Technology (Intel® IPT) | Nei |
| Intel® Wireless Display (Intel® WiDi) | Nei |
| Intel Virtualisering Technology for Directed I/O (VT-d) | Ja |
| Intel® Anti-Theft Technology (Intel® AT) | Nei |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Ja |
| Intel® My WiFi Technology (Intel® MWT) | Nei |
| Intel® Turbo Boost Technology | Ja |
| Intel® Quick Sync Video Technology | Nei |
| Intel® InTru™ 3D Technology | Nei |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Nei |
| Intel® Insider™ | Nei |
| Intel® Flex Memory Access | Ja |
| Intel® AES New Instructions (Intel® AES-NI) | Ja |
| Intel® Trusted Execution Technology | Ja |
| Intel® Enhanced Halt State | Ja |
| Intel® VT-x with Extended Page Tables (EPT) | Ja |
| Intel® Demand Based Switching | Ja |
| Intel Sikkerhets Nøkkel | Ja |
| Intel klar video teknologi | Nei |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID) | Nei |
| Intel® 64 | Ja |
| Intel® Identity Protection Technology version | 0,00 |
| Intel Secure Key Technology versjon | 1,00 |
| Intel® Virtualization Technology (VT-x) | Ja |
| Intel TSX-NI verson | 0,00 |
| Intel® Dual Display Capable Technology | Nei |
| Intel® FDI Technology | Nei |
| Intel® Fast Memory Access | Nei |
| Processor ARK ID | 64594 |
| Intel® vPro™ Platform Eligibility | Ja |
| Redundant strømforsyning | Ja |
| Krav til strømforsyning | 550 W |
| Antall overflødige strømforsyninger støttet | 2 |
| Antall hovedstrømforsyninger | 1 |
| Bredde | 445 mm |
| Dybde | 746 mm |
| Høyde | 86 mm |
| Harddisk hot swap | 8 |
| Videokontakter | G200eR2 |
| Grafikkadapterfamilie | Matrox |
